Condenser microphones are ideal if you want a mic with high sensitivity and output, although they are active and need a source of power. Most condenser mics run on phantom power, which is usually standard on microphone preamp inputs. But what happens if you use phantom power on a microphone that doesn’t need it?
Using phantom power on a microphone that does not need an external power source will not cause any damage, but there are exceptions. Passive ribbon mics or unbalanced dynamic mics can suffer extensive damage when used with phantom power. Keep phantom power off if your mic doesn’t need it.
Continue reading to learn how phantom power works and how it can harm certain equipment. This article will also tackle what types of microphones need phantom power and how to tell.
Table of Contents
- How Phantom Power Works
- Which Microphones Phantom Power
- How To Tell if Your Mic Needs Phantom Power
- Final Thoughts
How Phantom Power Works
Phantom power supplies active microphones or certain audio devices with DC (Direct Current) voltage ranging from 11 to 52 volts. Most audio interfaces and mixers provide the current standard of +48 volts DC through an XLR input.
XLR cables are commonly used for microphones that require phantom power since they are balanced. Balanced cables consist of two signal wires and a ground wire. The DC voltage travels through the signal wires in the opposite direction of the audio signal to give the mic the power it needs.
One trait of balanced cables is that they can cancel noise from electrical interference while preserving the original audio signal. Since the DC voltage is silently transmitted through the same cables used by the audio signal, it is called phantom power.
How Phantom Power Can Damage Equipment
Many passive microphones will simply reject the DC voltage supply when connected to phantom power input. However, you should still avoid using phantom power with devices that don’t need it since there are several scenarios where you could risk damaging your equipment.
Miswired or Worn-Out XLR Cables
The DC voltage from phantom power runs through the signal wires of an XLR cable, which are connected to pins 2 and 3. A ground cable is connected to pin 1, and if any of these wires are interchanged, the voltage can be sent directly to microphone components that cannot cope with the power supply.
Similarly, any tears in the wires can cause a short, which can also damage audio equipment.
Using Passive Equipment on Patchbays
Patchbays serve as a centralized hub for audio gear input and output connections. Connecting a patchbay to a phantom power input can send unnecessary power to the output terminals of the patchbay and damage the equipment connected there.
Most patchbays work with TRS (Tip-Ring-Sleeve) cables that are more prone to electrical shorting.
TRS cables are also balanced, but unlike XLR cables that establish a ground connection as the signal wires are connected, the construction of TRS cables establishes a connection with the signal wires (on the tip and ring) before the ground (at the sleeve) is connected.
And since the signal wires are connected first, it can short your equipment before the ground connection is made.
Power Surges
Electrical spikes during blackouts and power surges can also be harmful to your audio equipment. If an electrical surge occurs while you have phantom power, the sudden influx of energy can damage sensitive components of passive devices.
Damage is more likely to occur if your audio interface does not have a built-in regulator.
Damage is more likely to occur if your audio interface does not have a built-in regulator.
Which Microphones Phantom Power
Given the risks of unnecessarily using phantom power, it’s essential to know what types of microphones need phantom power and which don’t. There’s no rule of thumb when it comes to knowing which microphones require phantom power because there’s always an exception.
Most condenser mics need phantom power, while passive dynamic and ribbon mics don’t. However, some condenser mics work with a different power source. There are also active dynamic and ribbon mics that require phantom power.
Condenser Microphones
Condenser mics use variable capacitance and need a power source like phantom power to work. The capacitor in condenser mics consists of two conductive plates; a diaphragm and a magnetic plate.
Sound waves cause the diaphragm to vibrate, which moves the magnetic plate behind it to turn the acoustic energy into an electric audio signal.
Condenser mics need additional power to boost the voltage; otherwise, the signal will not be strong enough to be audible. Some condenser mics are powered through a USB port, while others have built-in batteries. So, even if condenser mics need a power source, not all of them will use phantom power.
Dynamic Microphones
Dynamic mics use electromagnetism to work and do not need additional power. Like condenser microphones, dynamic mics have a diaphragm that vibrates due to sound waves.
The difference in a dynamic mic is that the diaphragm moves a voice coil in a magnetic field to produce the electric audio signal.
Generally speaking, dynamic mics are passive and do not need a power source. However, there are active dynamic mics that use phantom power.
The Blue Encore 200 Microphone (available on amazon.com) is the world’s first studio-grade phantom-powered active dynamic microphone. This microphone delivers studio-quality sound on stage, giving you the best of both worlds: a condenser mic’s detail and clarity and the dynamic mic’s quietness.
Learn more about dynamic microphones: do they have higher gain requirements than condenser mics? The answer isn’t a straightforward yes or no! Do Dynamic Mics Need More Gain Than Condensers?
Ribbon Microphones
Ribbon mics are essentially dynamic mics that use a ribbon suspended in a magnetic field instead of a diaphragm. The ribbon serves the functions of the diaphragm and the voice coil, which allow ribbon mics to have highly detailed sound quality with good noise isolation.
Most ribbon mics are passive, but there are also active ribbon mics that have onboard electronics and require phantom power to work.
Phantom power can cause significant damage to passive ribbon mics, particularly when there is a power surge, faulty cables, or a miswired patch bay.
How To Tell if Your Mic Needs Phantom Power
One way to tell if your microphone needs phantom power is by connecting it to a mic input without phantom power; if the mic does not produce sound, it likely requires phantom power to work. However, it’s always best to check your microphone’s specifications or consult your owner’s manual to be sure.
If you’re in the process of buying a mic, don’t finalize your purchase until you’ve read my ultimate guide on choosing a mic that fits your needs and budget. You’ll learn about the essentials and nice-to-haves of the mics on the market. Ultimate Guide to Choosing the Right Microphone For You
Final Thoughts
Passive ribbon mics are the most sensitive to phantom power, given their ribbons’ fragility. A power surge and electrical short can render a passive ribbon microphone useless. Dynamic and ribbon mics typically do not need phantom power unless they are active.
Most condenser mics run on phantom power, but some are powered by an internal battery or USB port. It may not be clear whether a microphone needs phantom power, so you should check the owner’s manual or consult your microphone manufacturer if you’re unsure.
